Test Plants
Membrane-Pilot-Plant for the Extraction with supercritical CO2
This plant is used to investigate the permeation behaviour of gases and organic compounds through microporous ceramic membranes. Feed and permeate pressures are adjustable up to 400 bar.
Further information and pictures…
High-Pressure Gas Membrane Plant for Dynamic Measurements
This plant is used to investigate the permeation behaviour of single gases through microporous ceramic and carbon membranes in dynamic experiments.
Further information and pictures…
High-Pressure Gas Membrane Plant
This plant is used to investigatione the permeation behaviour of single gases through microporous ceramic and carbon membranes in static experiments.
Further information and pictures…
Membrane-Test-Units
For the investigation of the scaling behaviour of water hardness and silica, we developed a new membrane-based test method and we designed corresponding test units. There are 2 fully automatic operating units available for long-term test runs.
Further information and pictures…
Reverse Osmosis and Nano Filtration Test Plant
This plant is designed to investigate spiral-wound membrane modules (2,5", 4" and 8"), especially for reverse osmosis and nano filtration membranes.
The maximum operation pressure is 140 bar.
